Anti Glare Surface
60Hz
8 Bit
Pixel Format (H x V): 1368 x 768
Brightness (nit): 250 cd/m2
Contrast Ratio 3000:1
Composition: Analog / Digital
Digital Broadcasting Signal: CABLE, DVB-T / T2, DVB-S / S2, DVB-C
Video Format: MPEG-2 SD (MP@ML) ,HD (MP@HL),MPEG-4 SD (H.264 AVC Lv3.0),HD (H.264 AVC Lv4.0),H.265S
Audio Format: MPEG-1 Layer ?/?, MPEG-2 Layer ?/?, Dolby Digital, Dolby Digital Plus, AAC
Analog Broadcasting Signal: PAL, SECAM, NTSC
Subtitle (Closed Caption)
Audio Description
MTS: NICAM
Teletext: FLOF / TOP, Memory Page, Character language (Pan-Euro, Arabic, Farsi)
Composite Video: PAL 50/60Hz, SECAM, NTSC
HDMI Video format: 480i (60Hz) / 576i (50Hz) , 480p (60Hz) / 576p (50Hz), 720p (50/60Hz), 1080i (60Hz) / 1080i (50Hz), 1080p (50/60Hz)
Audio format: L-PCM / AC3 / AAC
Output Support Signals: Digital audio
Dolby Digital
Headphone Socket (3.5mm)
Main System
Main Processor: SoC Name (MSD3666LSAT-U9)
Software Update: Over-Air / Internet / Service Port(USB)
Software Upgrade Check
AC Input AC-Input Voltage: 100-240V 50/60Hz
AC Cable Length: 1.55m
Consumption Standby (W): Active Standby (W) Picture:
Comb Filter: PAL, NTSC
Noise Reduction(except PC) DNR / Auto DNR
MPEG NR
Picture mode: Dynamic, Standard, Mild, Personal
Manual: RF Analog/Video(480i/576i), RF Digital (288i/288p/576i/576p/720p), 1080i/1080p, HDMI (AV format, PC format)
4:3 Stretch
Color Temperature: 3 modes(Cool, standard, Warm
Dolby Sound
EQ
Sound Mode: Standard, Music, Movie, Sports, Personal
2 x Speakers
Output Power RMS: 8W 8W
HDD, PVR Function: USB memory, Time Shift, EPG schedule recording, Set start/end time recording, MPEG2/H.264 Transcoder
Terminals :
Antenna Input x 2
VIDEO/AUDIO CVBS,L/R(Mono L) x 1
HDMI terminals x 2
USB x 2
Output Digital
Headphone Socket (3.5mm)
USB 2.0 (Total Q'ty and direction) x 2
USB Supported HDD (0.5A)
Service Port Program update (USB)
Panel Lock (Key side lock)
Channel Manual sorting
Media Player: Movie(USB), Photo(USB), Music(USB)
USB Supported File System: (FAT16, FAT32, NTFS (NT File System)
Container /Format: Movie, Music, Photo
HDMI Ver.1.4a: ARC (Audio Return Channel)
CEC: Basic features, Routing Control, Standby, System Information
